Z4 laser gas generator

Zero Air Generator for Laser Protection

The Z4 zero air generator perform in 24/7 production process worldwide with utmost reliability. Even under the most challenging environments Z4s guarantee frictionless industrial use for different applications (example: high power UV-lasers (>300 nm)). The Generator produces a continuous flow of hydrocarbon-free air. The flow is controlled stable. All Generators reduce the total quantity of hydrocarbons to less than 0,01 ppm, establishing a stable flow for your application. Zero-air produced in this way replaces existing stocks of synthetic air stored in high pressure bottles.

Zero Air generators are designed specifically to supply clean, dry, hydrocarbon-free air to be used for several applications.

LNI Swissgas recognizes the importance of having a safe, reliable and cost effective supply of high-purity Zero Air.

In addition providing flexibility to add or remove modules as your application requirements evolve over time.


  • LED Indicators

  • Integrated pressure control (enhances catalyst life time)

  • Programmable catalyst temp

  • Alarm signal (1 output included)

  • Remote software

  • Integrated compressor (autarkic system

  • Supplying laser modules

  • Better quality than zero air with class 5.0

  • Customer specific configurations



Our generators continually protect optics, crystals and coatings of the laser beam path against particles, humidity, hydrocarbons and aggressive gases. Degradation and maintenance are reduced to a minimum. Lifetime and performance of the laser and optical systems are maximized.


Model: Z4 Z4
Zero Air outlet
Flow rate (max) >1.0 l/min
Outlet pressure (min) integrated pump
Outlet pressure (max) up to 1.4 bars
Total hydrocarbon content < 0.05ppm
Air inlet
Inlet integrated pump
RS232 Standard
General data
Supply voltage 100-240Vac 50/60Hz
Connection type IEC320-C13
Installation power (max) 240W (280VA)
Fuse rating (5x20mm) 4A
Dimensions Standard 19″ Rack (4U)
Net weight < 13 kg
Outlet port 1/8″ female BSPP
Inlet port 1/8″ female BSPP
Water purge Threaded ISO M5 female
Operating conditions
Temperature 5-35°C (41-95°F)
Humidity (max, non condensing)  80% at 25°C (77°F)
Noise <25dB(A)
IP rating IP20
